| Kamera | |
| Sensorius | 1/2.7'' Progressive Scan CMOS |
| Min. pašvietimas | 0.003 Lux @ (F1.4, AGC ON) |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Lėtas užraktas | Yes |
| WDR | 120 dB |
| Diena ir naktis | ICR Cut |
| Reguliavimo kampas | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Objektyvas | |
| Objektyvo tvirtinimas | 2.7 to 13.5 mm: Ø14
7 to 35 mm: Integrated |
| Auto-Iris | 2.7 to 13.5 mm: Yes
7 to 35 mm: Yes |
| Objektyvas ir matymo kampas | 2.7 to 13.5 mm: horizontal FOV 101° to 31°, vertical FOV 72.2° to 23.4°, diagonal FOV 138.8° to 39.8°
7 to 35 mm: horizontal FOV 27.2° to 10.4°, vertical FOV 20.3° to 7.5°, diagonal FOV 34.4° to 12.5° |
| Diafragma | 2.7 to 13.5 mm: F1.4
7 to 35 mm: F1.7 |
| Apšvietimas | |
| IR atstumas | 2.7 to 13.5 mm: up to 40 m
7 to 35 mm: up to 60 m |
| Bangos ilgis | 850 nm |
| Išmanus papildomas pašvietimas | Yes |
| Video | |
| Raiška | 2592 × 1944 |
| Pagrindinis srautas | 50Hz: 20 fps (2592 × 1944)
25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (2592 × 1944)
30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720) |
| Antrinis srautas | 50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
| Trečias srautas | 50Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
60Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Ketvirtas srautas | 50Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
60Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
*Fourth stream is supported under certain settings. |
| Video suspaudimas | Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Fourth stream: H.265/H.264/MJPEG
*Fourth stream is supported under certain settings. |
| Video Bit dažnis | 32 Kbps to 8 Mbps |
| H.264 | Baseline Profile/Main Profile/High Profile |
| H.265 | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit dažnių kontrolė | CBR/VBR |
| Video konfiguravimas (SVC) | H.265 and H.264 support |
| Įdomios sritys (ROI) | 5 fixed regions for main stream and sub-stream |
| Audio | |
| Aplinkos triukšmo filtravimas | Yes |
| Audio dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio suspaudimas | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit dažnis | 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8-320Kbps(MP3) |
| Tinklas | |
| Vienalaikė peržiūra | Up to 6 channels |
| API | Open Network Video Interface (PROFILE S, PROFILE G), ISAPI, SDK |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
| Vartotojai | Up to 32 users. 3 user levels: administrator, operator and user |
| Apsauga | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for Open Network Video Interface |
| Tinklinis talpinimas | MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Klientai | iVMS-4200, Hik-Connect, Hik-Central |
| Naršyklės | Plug-in required live view: IE 10, IE 11
Plug-in free live view : Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Vaizdas | |
| Diena / naktis perjungimas | Day, Night, Auto, Schedule |
| Objekto apkarpymas | Yes |
| Vaizdo gerinimas | BLC, HLC, 3D DNR |
| Vaizdo parametrai | Yes |
| Vaizdo nustatymai | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Sąsajos | |
| Alarmas | 2 inputs, 2 outputs (max. 24 VDC, 1 A; 24 VAC, 1 A) |
| Audio | 1 input (line in), max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;
1 output (line out), max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Vidinė atmintis | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Perkrovimas | Yes |
| Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Maitinimas | 12 VDC, max. 100 mA (supported by all power supply types) |
| Išmanūs įvykiai | |
| Pagrindiniai įvykiai | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Gylusis mokymasis | |
| Vaidų aptikimas | Yes |
| Perimetro apsauga | Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
| Bendriniai | |
| Apjungimo būdai | Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture |
| Kalbos | 33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Pagrindinės funkcijos | Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter |
| Programos perkrovimas | Yes |
| Laikymo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Darbinės sąlygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC ± 25%
PoE: 802.3af, class 3 |
Energijos sąnaudos
| 12 VDC, 0.92 A, max. 11 W
PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W |
| Maitinimo jungtis | Ø5.5 mm coaxial power plug |
| Madžiaga | Metal |
| Matmenys | Ø153.5 × 111.6 mm (6.0" × 4.4") |
| Pakuotės matmenys | 261 × 217 × 197 mm (10.3" × 8.5" × 7.8") |
| Svoris | Approx. 875 g (1.9 lb.) |
| Svoris su pakuote | Approx. 1456 g (3.2 lb.) |
| Patvirtinimai | |
| EMC | FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (IEC/EN 60950-1) |
| Aplinka | CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006) |
| Apsauga | IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
