| Kamera | |
| Sensorius | 1/2.7" Progressive Scan CMOS |
| Min. apšvietimas | Color: 0.003 Lux @ (F1.4, AGC ON) |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Lėtas užraktas | Yes |
| P/N | P/N |
| WDR | 120 dB |
| Diena / naktis | ICR Cut |
| Reguliavimo kampas | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Objektyvas | |
| Objektyvas ir matymo kampas | 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 123°
4 mm, horizontal FOV 83°, vertical FOV 45°, diagonal FOV 98°
6 mm, horizontal FOV 53°, vertical FOV 29°, diagonal FOV 62° |
| Diafragma | F1.4 |
| Objektyvo montavimas | M12 |
| Apšvietimas | |
| IR atstumas | Up to 30 m |
| Bangos ilgis | 850 nm |
| Išmani papildoma šviesa | Yes |
| Matomas aliarmas | Yes |
| Video | |
| Raiška | 2592 × 1944 |
| Pagrindinis srautas | 50Hz: 20fps (2592 × 1944)
25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2592 × 1944)
30fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720) |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Trečias srautas | 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240)
60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240) |
| Suspaudimas | Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bit dažnis | 32 Kbps to 8 Mbps |
| H.264 | Baseline Profile/Main Profile/High Profile |
| H.265 | Main Profile |
| H.264+ | Main Stream supports |
| H.265+ | Main Stream supports |
| Bit dažnio kontrolė | CBR/VBR |
| Video konfiguravimas (SVC) | Yes |
| Svarbio sritys (ROI) | 1 fixed region for each stream |
| Audio | |
| Aplinkos triukšmo filtravimas | Yes |
| Audio dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio suspaudimas | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit dažnis | 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/
8-320Kbps(MP3) |
| Tinklas | |
| Vienalaikė peržiūra | Up to 6 channels |
| API | ONVIF(PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Sklandus transliavimas | Yes |
| Vartotojai | Up to 32 users. 3 user levels: administrator, operator and user |
| Apsauga | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF |
| Tinklinis talpinimas | microSD/SDHC/SDXC card (256 GB) local storage, and NAS(NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Klientai | iVMS-4200, Hik-Connect, Hik-Central |
| Naršyklė | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Vaizdas | |
| Diena / naktis perjungimas | Day, Night, Auto, Schedule |
| Vaizdo pagerinimas | BLC, HLC, 3D DNR |
| Vaizdo parametrų perjungimas | Yes |
| Vaizdo nustatymai | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Sąsajos | |
| Aliarmas | 1 input, 1 output (max. 12 VDC, 30 mA) |
| Audio | 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;
1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium;
1 built-in speaker, 1 built-in microphone |
| Vidinė atmintis | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Perkrovimas | Yes |
| Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Tradicinis algoritmas | |
| Pagrindiniai įvykiai | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Gylusis mokymasis | |
| Veido aptikimas | Yes |
| Perimetro apsauga | Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
| Bendriniai | |
| Apjungimo būdai | Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audible warning
*Note: External device is required. |
| Kalbos | 33 languages:
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Pagrindinės funkcijos | Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel
counter |
| Programos perkrovimas | Yes |
| Laikymo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Darbinės sąlygos
| -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC, 0.65 A, max. 7.8 W
PoE: (802.3af, 36 V to 57 V), 0.25A to 0.15 A, max. 8.8 W |
| Energijos sąnaudos | Ø5.5 mm coaxial power plug |
| Maitinimo jungtis | 12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3 |
| Medžiaga | Metal except for trim ring |
| Matmenys | Ø138.3 × 124.5 mm (Ø5.4″ × 4.9″) |
| Pakuotės matmenys | 170 × 170 × 150 mm (6.9" × 6.9" × 5.9") |
| Svoris | Approx. 800 g (1.8 lb.) |
| Svoris su pakuote | Approx. 1093 g (2.4 lb.) |
| Patvirtinimai | |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN
61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
(ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 );
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Aplinka | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Apsauga | Ingression protection: IP66 (IEC 60529-2013) |
