| Kamera |
|---|
| Sensorius | 1/3" progressive scan CMOS |
| Efektyvūs taškai | 2560(H)×1440(V) |
| Signalo sistema | PAL/NTSC |
| Min. apšvietimas | Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR |
| Baltos spalvos balansas | Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC | Auto/Manual |
| HLC | Support |
| WDR | 120dB |
| Užrakto laikas | 50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s |
| Diena/naktis | ICR |
| Skaitmeninis artinimas | 16× |
| Privatumo maskavimas | 24 privacy masks programmable |
| Automatinis fokusavimas | Auto / Semi-automatic / Manual |
| Objektyvas |
|---|
| Objektyvas | 2.8 to 12mm, 4× optical zoom |
| Artinimo greitis | Approx. 2s (optical lens, wide-tele) |
| Matymo kampas | Horizontal field of view: 109° to 34° (Wide-Tele)
Vertical field of view: 57° to 19° (Wide-Tele)
Diagonal field of view: 135° to 39° (Wide-Tele) |
| Min. veikimo atstumas | 10 to 1500mm (wide-tele) |
| Diafragmos diapazonas | F1.6 to F2.7 |
| Horizontalus ir vertikalus reguliavimas |
|---|
| Horizontalus diapazonas | 0° to 330° |
| Horizontalus greitis | Configurable, from 0.1°/s to 100°/s,
Preset speed: 100°/s |
| Vertikalus diapazonas | Tilt: 0°~90° |
| Vertikalus greitis | Configurable, from 0.1°/s to 100°/s
Preset Speed: 100°/s |
| Proporcinis artinimas | Rotation speed can be adjusted automatically according to zoom multiples |
| Numatytasis skaičius | 300 |
| Atmintis po išjungimo | Support |
| Infrared apšvietimas |
|---|
| IR apšvietimo atstumas | 20m |
| IR apšvietimo kampas | Adjustable by zoom |
| Įvestys / išvestys |
|---|
| Garso įvestis | 1-ch audio input |
| Garso išvestis | 1-ch audio output |
| Tinklas |
|---|
| Tinklas | 10Base -T, /100Base-TX, RJ45 Connector |
| Maks. vaizdo raiška | 1920×1080 |
| Pagrindinis srautas | 50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
| Antrinis srautas | 50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Trečias srautas | 50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Vaizdo suspaudimas | Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG |
| ROI kodavimas | Support 2 areas with adjustable levels |
| Garso suspaudimas | G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Garso rėžimas | OFF/Audio input/Audio output |
| Protokolai | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Vartotojų skaičius | Up to 20 users |
| Trečias srautas | Support |
| Mini SD kortelė | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Vertotojų lygiai | Up to 32 users, 3 levels: Administrator, Operator and User |
| Apsauga | User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering |
| Hik-Connect | Support |
| Pagrindinės savybės |
|---|
| Maitinimas | 12 VDC & PoE |
| Energijos suvartojimas | Max.: 12 W (Max. 3.9 W for IR) |
| Darbo sąlygos | -20°C to 60°C (-4°F to 140°F) |
| IP apsaugos klasė | IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Medžiaga | Aluminum alloy, PC, PC+ABS |
| Išmatavimai | Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00") |
| Svoris | Approx. 0.53 kg (1.17 lb) |
