| Sensorius | 1/2.8″ Progressive Scan CMOS |
| Min.apšvietimas | Color: 0.005 Lux @(F1.2, AGC ON), 0.014 Lux @(F2.0, AGC ON),B/W: 0.0001 Lux @(F1.2, AGC ON), 0.0003 Lux @(F2.0, AGC ON) |
| Užrakto greitis | 1 s to 1/100,000 s |
| Lėtas užraktas | Support |
| Kampo valdymas | Not support |
| DNR | 3D DNR |
| WDR | 120dB |
| Diena / naktis | Electronic |
| Auto-Iris | No |
| Diafragma | L10, L20: F2.5,L30: F2.0 |
| FOV | Pin-hole: 2.8 mm @ F2.5, horizontal FOV 88.2°, vertical FOV:48.8° 3.7 mm @ F2.5, horizontal FOV 71°, vertical FOV:39.3° M12: 2.8 mm @ F2.0, horizontal FOV 104°, vertical FOV:56.8° 4.0 mm @ F2.0, horizontal FOV 80°, vertical FOV:42.9° 6.0 mm @ F2.0, horizontal FOV 50°, vertical FOV:28.8° |
| Montavimas | M12, pin hole |
| Židinio nuotolis | 2.8 mm/3.7 mm/4.0 mm/6.0 mm |
| Garso suspaudimas | Max. 48kHz |
| Garsas I/O | Yes |
| Vaizdo gerinimas | BLC, 3D DNR |
| Retušavimas | No |
| Diena/naktis perjungimas | Day/Night/Auto/Schedule/ Triggered by Alarm In |
| Paveikslėlio persidengimas | No |
| Vaizdo nustatymai | Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Maks. raiška | 1920 × 1080 |
| Pagrindinis srautas | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Tretinis srautas | 50Hz: 1fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 640 × 360, 352 × 288, 320 × 240),60Hz: 1fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 640 × 360, 352 × 240, 320 × 240) |
| Protokolai | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| API | v5.5.6 |
| Apsauga | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Transliavimas | ONVIF (PROFILE S, PROFILE G), ISAPI |
| User/Host | Up to 6 channels |
| Programinė įranga | Up to 32 users,3 levels: Administrator, Operator and User |
| Naršyklė | iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
| Saugykla | Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Programinės įrangos versija | One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter |
| Išmanios sąvybės | IE8+, Chrome31.0-44, Firefox30.0-51, Safari8.0+ |
| Ryšio protokolas | Built-in micro SD/SDHC/SDXC slot, up to 128 GB |
| Pavojaus signalas | 1 input (line in), 1 output (line out), mono |
| Vaizdo išvestis | 1 RJ45 10M/100M Ethernet port,1 VIN port,1 RS-485 |
| Vidinė atmintis | 1 input, 1 output (up to 24 VAC, 1A or 110 VAC, 500mA) |
| Sąsaja | Yes |
| H.264+ | Main stream support. |
| H.265+ | Main stream support. |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| Vaizdo suspaudimas | Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
| H.265 tipas | Main Profile |
| Garso suspaudimas | G.711/G.722.1/G.726/MP2L2/PCM |
| Vaizdo bitų greitis | 32 Kbps to 16 Mbps |
| Garso bitų greitis | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Tikslumas | Camera: 87 g (0.19 lbs.),With package: 220 g (0.49 lbs) |
| Veido aptikimas | Yes |
| Išimčių aptikimas | N/A |
| Elgesio analizė | Line crossing detection, intrusion detection, unattended baggage detection, object removal detection |
| ROI | 1 fixed region for main stream and sub stream |
| Maitinimas | -10 °C to +40 °C (-14 °F to +104 °F), Humidity 5% to 95%(non-condensing) |
| Svoris | Camera: 77.1 × 69 × 26 mm (3.04" × 2.72" × 1.02"),With package: 254 × 164 × 130 mm (10" × 6.46" × 5.12") |
| Suvartojimas | 12 VDC ± 20%, two-core terminal block, ,PoE: (802.3af, class 2) |
| Priedai | No |
| Pakuotės svoris | 12 VDC ± 20%, 0.25 A, max. 3 W,PoE: (802.3af, 36V-57V), 0.2A to 0.1A, Max: 3.5W |
| Medžiaga | Camera: Plastic,Lens: Metal |
