| Vaizdo suspaudimas | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Kodavimo raiška | When 1080p lite mode is not enabled: ,4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF,When 1080p Lite mode is enabled: ,4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF, |
| Bitų greitis | Main stream:,When 1080p Lite mode not enabled: ,For 4 MP stream access:,4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) ,For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps,For 1080p stream access: ,1080p/720p @15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N),For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N),When 1080p Lite mode enabled: ,4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N),Sub-stream: ,WD1/4CIF@12fps; CIF@25fps (P)/30fps (N), |
| Vaizdo bitų greitis | 32 Kbps to 6 Mbps |
| Dvigubas srautas | Support |
| Srauto tipas | Video, Video & Audio |
| Vaizdo suspaudimas | G.711u |
| Garso bit7 greitis | 64 Kbps |
| IP vaizdo įvestis | 8-ch (up to 24-ch) Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
| Analoginė vaizdo įvestis | 16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| AHD įvestis | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| HDCVI įvestis | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS įvestis | PAL/NTSC |
| Garso įvestis | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Garso išvestis | 1-ch, RCA (Linear, 1 KΩ) |
| Dvigubas garso apsikeitimas | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Sinchroninis atkūrimas | 16-ch |
| HDTVI įvestis | 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 *: The 3 MP signal input is only available for channel 1 of DS-7204HQHI-K1/P, channel 1/2 of DS-7208HQHI-K2/P, and channel 1/2/3/4 of DS-7216HQHI-K2/P. |
| VGA/HDMI išvestis | VGA: 1-ch, ,1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz,HDMI: 1-ch, ,4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, ,1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz, |
| PoC kameros įvestis | Support Hikvision PoC camera *: PoC access capability see Appendix. |
| CVBS išvestis | 1-ch, BNC (1.0 Vp-p, 75 Ω),resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Nuotolinis prisijungimas | 128 |
| Tinklo protokolai | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Tinklo sąsajos | 1,,RJ45 10M/100M/1000M ,self-adaptive ,Ethernet interface, |
| SATA | 2 SATA interfaces |
| Talpa | Up to 10 TB capacity for each disk |
| Pavojaus signalo įvestis/išvestis | N/A |
| USB sąsaja | Front panel: 1 × USB 2.0 ,Rear panel: 1 × USB 3.0 |
| Serijinė sąsaja | RS-485 (half-duplex) |
| Maitinimas | 48 VDC |
| Darbo temperatūra | -10 °C to +55 °C (+14 °F to +131 °F) |
| Darbo drėgmė | 10% to 90% |
| Matmenys (P × G × A) | 380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
| Svoris (be HDD) | ≤ 2 kg (4.4 lb) |
| Suvartojimas (be HDD) | ≤ 120 W |
