| Vaizdo/garso įvestis |
|---|
| Garso įvestis | 1-ch |
| Vaizdo suspaudimas | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Analoginė ir HD-TVI vaizdo įvestis | 8-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Palaikomi kamerų tipai | Support HDTVI input: 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
Note: The 3 MP signal input is only available for channel 1/2 of DS-7208HQHI-K2, and for channel 1/2/3/4 of DS-7216HQHI-K2.
Support AHD input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
Support CVI input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
Support CVBS input |
| Vaizdo įvesties sąsaja | BNC (1.0 Vp-p, 75Ω) |
| Garso suspaudimas | G.711u |
| Garso įvesties sąsaja | RCA (2.0 Vp-p, 1 kΩ) |
| Dvipusis garso ryšys | 1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input) |
| Vaizdo/garso išvestis |
|---|
| CVBS išvestis | 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| HDMI/VGA išvestis | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Rašymo raiška | When 1080p Lite mode not enabled:
4 MP lite/3 MP/1080p/1080p lite/720p/WD1/4CIF/VGA/CIF
When 1080p Lite mode enabled:
4 MP lite/3 MP/1080p lite/720p/720p lite/WD1/4CIF/VGA/CIF |
| Kadrai per sek. | Main stream:
When 1080p Lite mode not enabled:
For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access: 1080p@15fps; 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
| Vaizdo sparta | 32 Kbps-6 Mbps |
| Srauto tipas | Video/Video&Audio |
| Dvipusis graso ryšys | 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
| Garso išvestis | 1-ch RCA(Linear, 1kΩ) |
| Garso sparta | 64kbps |
| Dvigubas srautas | Support |
| Sinchroninis atkūrimas | 8-ch |
| Tinklo valdymas |
|---|
| Nuotoliniai prisijungimai | 64 |
| Tinklo protokolai | TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Kietasis diskas |
|---|
| Sąsajos tipas | 2 SATA Interfaces |
| Talpa | Up to 10 TB capacity for each disk |
| Išorinė sąsaja |
|---|
| Tinklo sąsaja | 1; 10M / 100M self-adaptive Ethernet interface |
| USB sąsaja | 2 USB 2.0 Interfaces |
| Serial sąsaja | 1; standard RS-485 serial interface, half-duplex |
| Pagrindinės savybės |
|---|
| Maitinimas | 12 VDC |
| Energijos suvartojimas | ≤ 7.5W(without hard disks) |
| Veikimo temperatūra | -10 oC to +55 oC (14 oF to 131 oF) |
| Santykinis oro drėgnumas | 10% to 90% |
| Išmatavimai | 380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
| Svoris | ≤ 1.78 kg (3.9 lb) |
