| Kamera |
|---|
| Sensorius | 1/2" Progressive Scan CMOS |
| Signalo sistema | PAL/NTSC |
| Min. apšvietimas | Color: 0.008 Lux @ (F1.2, AGC ON), 0.011 Lux @ (F1.4, AGC ON) |
| Užrakto laikas | 1/3 s to 1/100,000 s |
| Lėtas užraktas | Support |
| Objektyvas | 2.8 to 12 mm |
| Objektyvo montavimas | φ14 |
| Reguliavimas | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Diena/naktis | IR cut filter with auto switch |
| Platus dinaminis diapazonas | 120 dB |
| Skaitmeninis triukšmo slopinimas | 3D DNR |
| Fokusavimas | Auto |
| Suspaudimo standartai |
|---|
| Vaizdo suspaudimas | H.265+/H.265/H.264+/H.264/MJPEG |
| Vaizdo sparta | 32Kbps~16Mbps |
| Garso suspaudimas | G.711/G.722.1/G.726/MP2L2/PCM |
| Garso sparta | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Trigubas srautas | Yes |
| Vaizdas |
|---|
| Maks. vaizdo raiška | 3840 × 2160 |
| Kadrai per sek. | 50Hz: 20 fps (3840 × 2160), 25 fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (3840 × 2160), 30 fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Trečias srautas | 50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240) |
| Foninio apšvietimo kompensavimas | BLC/3D DNR/ROI/HLC |
| Vaizdo nustatymai | Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| ROI | Support 1 fixed region for main stream and sub stream separately |
| Dienos/nakties perjungimas | Day/Night/Auto/Schedule/Triggered by Alarm In |
| Tinklas |
|---|
| Tinklinis talpinimas | microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Pavojaus signalo sukėlimas | Motion detection, tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Pagrindinės funkcijos | One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video
mask, Watermark, IP address filtering |
| Sistemos suderinamumas | ONVIF (Profile S, Profile G), ISAPI |
| Sąsaja |
|---|
| Garsas | 1 input (line in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound |
| Ryšio sąsaja | 1 RJ45 10M / 100M Ethernet interface |
| Pavojaus signalas | 1 input, 1 output (max. 12 VDC, 30 mA), terminal block |
| Vaizdo išvestis | 1Vp-p Composite Output(75Ω/CVBS) (For adjustment only) |
| Vidinė atmintis | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset mygtukas | Yes |
| Garsas |
|---|
| Aplinkinių garsų filtravimas | Support |
| Garso testavimo dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz |
| Išmanios funkcijos |
|---|
| Elgesio analizė | Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Linijos kirtimo aptikimas | Cross a pre-defined virtual line |
| Įsibrovimo aptikimas | Enter and loiter in a pre-defined virtual region |
| Neprižiūrimas bagažas | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Objektų karpymas | Objects removed from the pre-defined region, such as the exhibits on display. |
| Nuspėjimų aptikimas | Scene change detection |
| Atpažinimas | Face Detection |
| Pagrindinės savybės |
|---|
| Veikimo sąlygos | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC ± 25%, PoE (802.3af Class3) |
| Energijos suvartojimas | 12 VDC, 0.9A, max. 10.5W
PoE: (802.3af, 36V to 57V), 0.4A to 0.2A, max. 12.5W |
| Smūgio apsauga | IK10 |
| IP apsaugos klasė | IP67 |
| IR apšvietimas | Up to 30m |
| Išmatavimai | Camera: Φ 153.4 × 133.1 mm (Φ 6" × 5.2") |
| Svoris | Camera: 1300 g (2.9 lb.)
With package: 1500 g (3.3 lb.) |
