| Kamera |
|---|
| Sensorius: | 1/2.9" Progressive Scan CMOS |
| Signalas: | PAL/NTSC |
| Min. apšvietimas: | Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Užrakto laikas: | 1/3 s to 1/100,000 s |
| Užrakto išlaikymas: | Support |
| Objektyvas: | 2.8 mm, horizontal FOV: 97°, vertical FOV: 63°, diagonal FOV: 120°
4 mm, horizontal FOV: 78°, vertical FOV: 50°, diagonal FOV: 97°
6 mm, horizontal FOV: 60°, vertical FOV: 39°, diagonal FOV: 75° |
| Montavimas: | M12 |
| Reguliavimas: | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Diena / Naktis: | IR cut filter with auto switch |
| WDR: | 120 dB |
| DNR: | 3D DNR |
| Fokusavimas: | Fixed |
| Suspaudimo standartai |
|---|
| Vaizdo suspaudimas: | H.265+/H.265/H.264+/H.264/MJPEG |
| Vaizdo sparta: | 32Kbps~16Mbps |
| Trigubas srautas: | Yes |
| Vaizdas |
|---|
| Maks. raiška: | 3072 x 2048 |
| Kadrai per sek.: | 50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×
720)
60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 ×
720) |
| Antrinis srautas: | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas: | 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Fono apšvietimo kompensavimas: | BLC/3D DNR/BLC |
| Vaizdo nustatymai: | Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| Taikinio didinimas: | No |
| BLC: | Support |
| ROI: | 1 fixed region for main stream and sub-stream |
| Diena/naktis perjungimas: | Day/Night/Auto/Schedule |
| Tinklas |
|---|
| Tinklo saugykla: | microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Pavojaus signalas: | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protokolai: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, Bonjour |
| Pagrindinės funkcijos: | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering |
| Sistemų suderinamumas: | ONVIF (Profile S, Profile G),ISAPI |
| Sąsaja |
|---|
| Garsas: | 1 audio input (built-in mic), mono sound(-U) |
| Ryšio sąsaja: | 1 RJ45 10M / 100M Ethernet interface |
| Papildoma saugykla: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Perkrovimo mygtukas: | Yes |
| Išmaniųjų funkcijų rinkinys |
|---|
| Elgesio analizė: | Line crossing detection, intrusion detection |
| Linijos kirtimo aptikimas: | Cross a pre-defined virtual line |
| Įsibrovimo aptikimas: | Enter and loiter in a pre-defined virtual region |
| Atpažinimas: | Face Detection |
| Pagrindinės sąvybės |
|---|
| Darbo sąlygos: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Maitinimas: | 12 VDC ± 25%, PoE (802.3af Class3) |
| Suvartojimas: | 12 VDC, 0.5 A, max. 6.0W
PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 7.5W |
| Apsauga: | Without -U: IP67 With -U: IP66 |
| IR nuotolis: | Up to 30m |
| Išmatavimai: | Camera: Φ 127.3 × 95.9 mm (5" × 3. 8")
With package: 150 × 150 × 141 mm (5.9" × 5.9" × 5.6") |
| Svoris: | Camera: Approx. 635 g (1.4 lb.)
With package: Approx. 890 g (1.96 lb.) |
