| Sensorius | 1/2.7" Progressive Scan CMOS |
| Min.apšvietimas | Color: 0.003 Lux @ (F1.4, AGC ON) |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| DIena / naktis | ICR Cut |
| Lėtas užraktas | Yes |
| Kampo valdymas | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| P/N | P/N |
| WDR | 120 dB |
| Objektyvas & FOV | 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 123° 4 mm, horizontal FOV 83°, vertical FOV 45°, diagonal FOV 98° 6 mm, horizontal FOV 53°, vertical FOV 28°, diagonal FOV 62° |
| Diafragma | F1.4 |
| Montavimas | M12 |
| Diafragmos tipas | Fixed |
| IR atstumas | Up to 30 m |
| Bangos ilgis | 850 nm |
| Išmanus papildomas pašvietimas | Yes |
| Papildomo apšietimo tipas | IR |
| Maks.raiška | 2592 × 1944 |
| Pagrindinis srautas | 50Hz: 20fps (2592 × 1944) 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2944 × 1656) 30fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720) |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas | 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240) |
| Vaizdo suspaudimas | Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Vaizdo bitų greitis | 32 Kbps to 8 Mbps |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| H.265 tipas | Main Profile |
| H.264+ | Main Stream supports |
| H.265+ | Main Stream supports |
| Bitų greičio valdymas | CBR/VBR |
| SVC | Yes |
| ROI | 1 fixed regions for each stream |
| Aplinkos triukšmo filtravimas | Yes |
| Garso ėminių dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Garso suspaudimas | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3 |
| Garso bitų greitis | 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8-320Kbps(MP3) |
| Tiesioginė transliacija | Up to 6 channels |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Sklandus transliavimas | Yes |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Apsauga | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF |
| Tinklo saugykla | microSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported |
| Klientas | iVMS-4200, Hik-Connect, Hik-Central |
| Naršyklė | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Day/Night perjungimas | Day, Night, Auto, Schedule |
| Vaizdo pagerinimas | BLC, HLC, 3D DNR |
| Vaizdo nustatymų pakeitimas | Yes |
| Vaizdo nustatymai | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Aliarmas | -SU: 1 input, 1 output (max. 12 VDC @30 mA) |
| Garsas | -SU: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 100 Ω, interface type: non-equilibrium |
| Mikrofonas | Yes |
| Vidinė saugykla | Built-in micro SD slot, up to 256 GB |
| Perkrovimas | Yes |
| Ryšio protokolas | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Pagrindiniai įvykiai | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Veidų aptikimas | Yes |
| Papildomi įvykiai | Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
| Saugyklos sąlygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startas ir veikimo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC ± 25%, reverse polarity protection PoE: 802.3af, class 3 |
| Suvartojimas | 12 VDC, 0.45 A, max. 5.4 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 6.5 W |
| Galios sąsaja | Ø5.5 mm coaxial power plug |
| Medžiaga | Metal upper cover and base |
| Matmenys | Ø121 × 92 mm (4.8" × 3.6") |
| Pakuotės matmenys | 150 × 150 × 141 mm (5.9" × 5.9" × 5.6") |
| Kameros svoris | 585 g (1.3 lb.) |
| Su pakuote | 836 g (1.8 lb.) |
| Susiejimo metodai | Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audible warning *Note: External device is required. |
| Programinės įrangos kalba | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Pagridinės funkcijos | Anti- flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter |
| Programinės įrangos perkrovimas | Yes |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Aplikosauginiai sertifikatai | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Apsauga | -ISU: Ingression protection: IP66 (IEC 60529-2013), IK10 (IEC 62262:2002) -I: Ingression protection: IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
