| Kamera |
|---|
| Sensorius: | 1/2.5" Progressive Scan CMOS |
| Signalas: | PAL/NTSC |
| Min. apšvietimas: | Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Užrakto laikas: | 1/3 s to 1/100,000 s |
| Užlaikymas: | Support |
| Objektyvas: | 2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124°
4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 95°
6 mm, horizontal FOV: 50°, vertical FOV: 28°, diagonal FOV: 59°
8 mm, horizontal FOV: 40°, vertical FOV: 25°, diagonal FOV: 53° |
| Montavimas: | M12 |
| Reguliavimas: | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Diena/Naktis: | IR cut filter with auto switch |
| WDR: | 120 dB |
| DNR: | 3D DNR |
| Fokusavimas: | Fixed |
| Suspaudimas |
|---|
| Vaizdo suspaudimas: | H.265+/H.265/H.264+/H.264/MJPEG |
| Vaizdo sparta: | 32Kbps~16Mbps |
| Trys srautai: | Yes |
| Vaizdas |
|---|
| Maks. raiška: | 3840 × 2160 |
| Antrinis srautas: | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Kadrai per sek.: | 50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Trečias srautas: | 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Foninio apšvietimo kompensavimas: | BLC/3D DNR/ROI/HLC |
| Vaizdo nustatymai: | Saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| Apdorojimas: | No |
| ROI: | 1 fixed region for main stream and sub-stream |
| Diena/naktis jungiklis: | Day/Night/Auto/Schedule |
| Tinklas |
|---|
| Saugykla: | microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Pavojaus detekcija: | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protokolai: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Pagrindinė funkcija: | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering |
| Sistemos suderinamumas: | ONVIF (Profile S, Profile G),ISAPI |
| Sąsaja |
|---|
| Ryšio sąsaja: | 1 RJ45 10M / 100M Ethernet interface |
| Vidinė atmintis: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Perkrovimo mygtukas: | Yes |
| Išmanios funkcijos |
|---|
| Elgesio analizė: | Line crossing detection, intrusion detection |
| Linijos kirtimo nustatymas: | Cross a pre-defined virtual line |
| Įsilaužimo nustatymas : | Enter and loiter in a pre-defined virtual region |
| Atpažinimas: | Face Detection |
| Pagrindinės |
|---|
| Veikimo sąlygos: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Maitinimas: | 12 VDC ± 25%, PoE (802.3af Class3) |
| Suvartojimas: | 12 VDC, 0.5 A, max. 6 W
PoE: (802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 7.5W |
| Apsaugos lygis: | IP67 |
| IR atstumas: | Up to 30m |
| Išmatavimai: | Camera: Φ 70 mm × 155 mm (Φ 2.8" × 6.1")
Package: 216 × 121 × 118 mm (8.5" × 4.8" × 4.7") |
| Svoris: | Camera: approx. 410 g (0.9 lb.) |
