| Title | Description |
| FOV | Horizontal field of view: 57.6° to 2.5° (wide-tele),Vertical field of view: 34.4° to 1.4° (wide-tele),Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Pritraukimo greitis | Approx. 3.2 s (optical lens, wide-tele) |
| Veikimo atstumas | 10 mm to 1500 mm (wide-tele) |
| Diagragma | F1.6 to F3.5 |
| Židinio nuotolis | 4.8 mm to 120 mm, 25× optical |
| Vaizdo apdorojimas | HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus |
| Antrinis srautas | 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Maks. raiška | 1920 × 1080 |
| Pagrindinis srautas | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),50fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720),60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Tretinis srautas | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Tinklo saugykla | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
| Protokolai | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API | Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform |
| Transliavimas | Up to 20 channels |
| User/Host | Up to 32 users. ,3 levels: Administrator, Operator and User |
| Programinė įranga | iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
| Naršyklė | IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| Apsaugos priemonės | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Pavojaus signalo susiejimas | Alarm actions, such as Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc. |
| Pavojaus signalo išvestis | 1 alarm output |
| Pavojaus signalo įvestis | 1 alarm input |
| Garso išvestis | 1 audio input |
| Garso įvestis | 1 audio output |
| Tinklo sąsaja | 1 RJ45 10 M/100 M Ethernet Interface; PoE+ (802.3 at, class4) |
| H.264+ | Support |
| H.265+ | Support |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| Vaizdo suspaudimas | Main Stream: H.265+/H.265/H.264+/H.264,Sub-Stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG |
| H.265 tipas | Main Profile |
| Vaizdo bitų greitis | 32 Kbps to 16384 Kbps |
| Garso suspaudimas | G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
| Garso bitų greitis | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps (MP2L2) |
| SVC | Support |
| AGC | Auto/Manual |
| Sensorius | 1/2.8" progressive scan CMOS |
| Min.apšvietimas | Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR |
| Baltos spalvos balansas | Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| Užrakto laikas | 1/1 s to 1/30,000 s |
| Day & Night | IR Cut Filter |
| Skaitmmeninis priartinimas | 16× |
| Privatumo kaukė | 24 programmable privacy masks |
| Fokusavimo režimas | Auto/Semi-automatic/Manual |
| WDR | 120 dB WDR |
| IR atstumas | 50 m |
| Smart IR | Support |
| Judesio atstumas (Pan) | 360° endless |
| Pan greitis | Configurable, from 0.1°/s to 300°/s,Preset Speed: 350°/s |
| Judesio atstumas (Tilt) | From -5° to 90° (auto-flip) |
| Tilt greitis | Configurable, from 0.1°/s to 160°/s,Preset Speed: 200°/s |
| Proporcingas pritraukimas | Support |
| Nustatymai | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory | Support |
| Park Action | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| PTZ Status Display | Support |
| Preset Freezing | Support |
| Nustatoma užduotis | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output |
| Bazinio įvykio aptikimas | Motion Detection, Video Tampering Detection, Alarm Input, Alarm Output, Exception |
| Išmanus aptikimas | Audio Exception Detection, Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection |
| Išmanus stebėjimas | Manual Tracking, Auto Tracking, Event Tracking |
| Išmanus įrašymas | ANR (Automatic Network Replenishment), Dual-VCA |
| ROI | Main stream, sub-stream, and third stream respectively support four fixed areas. |
| Medžiaga | ADC12, PC, PC+ABS, SUS304, POM |
| Matmenys | Φ 169 mm × 161 mm (Φ 6.65" × 6.34") |
| Svoris | Approx. 2.45 kg (5.40 lb) |
| Apsaugos lygis | IP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Galia | 12 VDC & PoE+ (802.3 at, class4), Max.:18 W (IR Max.5 W) |
| Darbinė temperatūra | -30°C to 65°C (-22°F to 149°F) |
| Darbinė drėgmė | ≤ 90% |
| Instaliavimas | Variable installation methods optional, including ceiling mounting (default), in-ceiling mounting, pendant mounting and wall mounting |
