| Pavadinimas | Aprašymas |
| Sensorius | 1/1.8" Progressive Scan CMOS |
| Min. apšvietimias | Color: 0.003 Lux @ (F1.4, AGC ON), 0 Lux with IR |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Užrakto išlaikymas | Yes |
| WDR | 120dB |
| Diena/Naktis | ICR Cut |
| Kampo valdymas | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Išsijungimo atmintis | Yes |
| Fokusavimas | Auto |
| Objektyvo tipas ir matymo kampas | 2.8 to 12 mm, horizontal FOV 108° to 45°, vertical FOV 58° to 25°, diagonal FOV 127° to 52° |
| Diafragma | F1.4 |
| Lešio montavimas | Φ14 |
| IR atstumas | Up to 40 m |
| Bangos ilgis | 850 nm |
| Išmani papildoma šviesa | Yes |
| Maks. raiška | 3840 × 2160 |
| Pagrindinis srautas | 50Hz: 20fps (3840 × 2160, 3072 × 1728) 25fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 ×2160, 3072 × 1728) 30fps (2688 × 1520, 1920 × 1080, 1280 × 720) * When the main stream resolution is 3840 × 2160, max frame rate is 20 fps for all streams. |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas | 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Vaizdo suspaudimas | Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bitų greitis | 32 Kbps to 16 Mbps |
| H.264 tipas | BaseLine Profile, Main Profile, High Profile |
| H.265 tipas | Main Profile |
| Srauto tipas | Main stream/sub-stream/third stream |
| SVC | H.265 and H.264 support |
| ROI | 1 fixed region for each stream |
| Garso ėminių dažnis | 8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz |
| Garso suspaudimas | G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Garso bitų dažnis | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Garso tipas | Mono sound |
| Transliavimas | Up to 6 channels |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS |
| Sklandus transliavimas | Yes |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Apsauga | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS 1.2 |
| Tinklo saugykla | MicroSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Klientas | iVMS-4200, Hik-Connect, Hik-Central |
| Interneto naršyklė | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Dienos/nakties jungiklis | Day, Night, Auto, Schedule, Triggered by Alarm In |
| Vaizdo gerinimas | BLC, HLC, 3D DNR |
| Vaizdo nustatymai | Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software and web browser |
| Pavojaus signalas | 1 input, 1 output (max. 24 VDC, 1A, 24 VAC, 1A) |
| Garsas | 1 input (line in), 3.5 mm three-connector, 1 output (line out), 3.5 mm three-connector |
| Vidinė atmintis | Built-in micro SD slot, up to 256 GB |
| Perkrovimo funkcija | Yes |
| Etherneto jungtis | 10M/100M self-adaptive Ethernet port |
| Gilaus mokymosi funkcija | Yes |
| Aplinkos apsauga | Intrusion detection, line crossing detection, region entrance detection, region exiting detection (Human&Vehicle classification) |
| Išmanus(tradicinis algoritmas) | Yes |
| Paprastosios funkcijos | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),Scene change detection |
| Programinės įrangos kalba | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Pagrindinės funkcijos | Mirror, password protection, privacy mask, watermark, IP address filter, one-key reset, anti-flicker, three streams, heartbeat |
| Programinės įrangos perkrovimo mygtukas | Yes |
| Pranešimų perdavimas | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning |
| Laikymo salygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Pradėjimo ir veikimo salygos | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC ± 25%, two-core terminal block; PoE: 802.3af, Class 3 |
| Suvartojama įtampa ir srovė | 12 VDC, 0.9 A, max. 10.8 W PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W |
| Galios sąsaja | 2-core terminal block |
| Kameros išmatavimai | Φ153.5 × 133.2 mm (Φ6″ × 5.2″) |
| Pakuotės išmatavimai | 244 × 174 × 173 mm (9.6" × 6.9" × 6.8") |
| Kameros svoris | 1080 g (2.4 lb.) |
| Svoris su pakuote | 1671 g (3.7 lb.) |
| Apsauga | Ingress protection: IP66 (IEC 60529-2013), IK10 (IEC 62262:2002) |
| EMC | CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Aplinkos Sauga | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
