| Sensorius | 1/1.8" Progressive Scan CMOS |
| Min.apšvietimas | Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Lėtas užraktas | Yes |
| Diena / naktis | IR Cut Filter |
| Kampo valdymas | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| WDR | 120 dB |
| Objektyvas | Fixed lens, 2.8/4/6 mm |
| Diafragma | F1.6 |
| FOV | 2.8 mm, horizontal FOV: 110.7° , vertical FOV: 59.1° , diagonal FOV: 131° 4 mm, horizontal FOV: 87.1° , vertical FOV: 47.4° , diagonal FOV: 101.8° 6 mm, horizontal FOV: 50.8° , vertical FOV: 27.6° , diagonal FOV: 60° |
| Montavimas | M16 |
| IR atstumas | Up to 30 m |
| Bangos ilgis | 850 nm |
| Max.raiška | 3840 × 2160 |
| Pagrindinis srautas | 50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720) |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas | 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Vaizdo suspaudimas | Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| H.265 tipas | Main Profile |
| Vaizdo bitų greitis | 32 Kbps to 16 Mbps |
| Vaizdo kodavimas | H.264 and H.265 encoding support |
| Garso suspaudimas | G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Garso bitų greitis | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Aplinkos triukšmo filtraimas | Yes |
| Garso dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Pagrindiniai įvykiai | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Papildoma apsauga | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human&Vehicle classification) |
| ROI | 1 fixed region for main stream, sub-stream and third stream |
| Susiejimas | Upload to FTP/NAS/memory card, notify surveillance center, send email, alarm output, audible warning, trigger capture |
| Vaizdo gerinimas | BLC, HLC, 3D DNR |
| Vaizdo nustatymas | Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Day/Night perjungimas | Day/Night/Auto/Schedule |
| TInklo saugykla | microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Apsauga | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Transliavimas | Up to 6 channels |
| User/Host | Up to 32 users, 3 levels: administrator, operator and user |
| Kliento programinė įranga | iVMS-4200, Hik-Connect, Hik-Central |
| Naršyklė | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Garsas | Built-in microphone |
| Vidinė atmintis | Built-in micro SD slot, up to 256 GB |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Cheminių medžiagų sertifikatai | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Apsauga | Ingress protection: IP66 (IEC 60529-2013), IK10(IEC 62262:2002) |
| Programinės įrangos kalbos | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Pagrindinės funkcijos | Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter |
| Reset | Reset via reset button on camera body, web browser and client software |
| Startas ir darbo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Saugyklos sąlygos | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC ± 25%, Φ 5.5 mm coaxial power plug; reverse polarity protection; PoE (802.3af, class 3) |
| Suvartojimas | 12 VDC, 0.48 A, max. 5.8 W; PoE (802.3af, 36 V to 57 V), 0.19 A to 0.12 A, max. 6.8 W |
| Medžiaga | Metal |
| Išmatavimai | Camera: Φ 138.3 × 126.3 mm (Φ 5.4" × 5") With package: 170 × 170 × 150 mm (7" × 7" × 5.9") |
| Svoris | Camera: approx. 740 g (1.6 lb.) With package: approx. 1060 g (2.3 lb.) |
