Kamera |
|
|
Sensorius |
1/2.7" Progressive Scan CMOS |
|
Min. apšvietimas |
Color: 0.003 Lux @ (F1.4, AGC ON) |
|
Užrakto greitis |
1/3 s to 1/100,000 s |
|
Lėtas užraktas |
Yes |
|
P/N |
P/N |
|
WDR |
120 dB |
|
Diena / naktis |
ICR Cut |
|
Reguliavimo kampas |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
|
Objektyvas |
|
|
Objektyvas ir matymo kampas |
2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 123°
4 mm, horizontal FOV 83°, vertical FOV 45°, diagonal FOV 98°
6 mm, horizontal FOV 53°, vertical FOV 29°, diagonal FOV 62° |
|
Diafragma |
F1.4 |
|
Objektyvo montavimas |
M12 |
|
Apšvietimas |
|
|
IR atstumas |
Up to 30 m |
|
Bangos ilgis |
850 nm |
|
Išmani papildoma šviesa |
Yes |
|
Matomas aliarmas |
Yes |
|
Video |
|
|
Raiška |
2592 × 1944 |
|
Pagrindinis srautas |
50Hz: 20fps (2592 × 1944)
25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2592 × 1944)
30fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720) |
|
Antrinis srautas |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
|
Trečias srautas |
50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240)
60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240) |
|
Suspaudimas |
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
|
Video Bit dažnis |
32 Kbps to 8 Mbps |
|
H.264 |
Baseline Profile/Main Profile/High Profile |
|
H.265 |
Main Profile |
|
H.264+ |
Main Stream supports |
|
H.265+ |
Main Stream supports |
|
Bit dažnio kontrolė |
CBR/VBR |
|
Video konfiguravimas (SVC) |
Yes |
|
Svarbio sritys (ROI) |
1 fixed region for each stream |
|
Audio |
|
|
Aplinkos triukšmo filtravimas |
Yes |
|
Audio dažnis |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
|
Audio suspaudimas |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3 |
|
Audio Bit dažnis |
64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/
8-320Kbps(MP3) |
|
Tinklas |
|
|
Vienalaikė peržiūra |
Up to 6 channels |
|
API |
ONVIF(PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
|
Protokolai |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
|
Sklandus transliavimas |
Yes |
|
Vartotojai |
Up to 32 users. 3 user levels: administrator, operator and user |
|
Apsauga |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF |
|
Tinklinis talpinimas |
microSD/SDHC/SDXC card (256 GB) local storage, and NAS(NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
|
Klientai |
iVMS-4200, Hik-Connect, Hik-Central |
|
Naršyklė |
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
|
Vaizdas |
|
|
Diena / naktis perjungimas |
Day, Night, Auto, Schedule |
|
Vaizdo pagerinimas |
BLC, HLC, 3D DNR |
|
Vaizdo parametrų perjungimas |
Yes |
|
Vaizdo nustatymai |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
|
Sąsajos |
|
|
Aliarmas |
1 input, 1 output (max. 12 VDC, 30 mA) |
|
Audio |
1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;
1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium;
1 built-in speaker, 1 built-in microphone |
|
Vidinė atmintis |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
|
Perkrovimas |
Yes |
|
Ryšio sąsaja |
1 RJ45 10M/100M self-adaptive Ethernet port |
|
Tradicinis algoritmas |
|
|
Pagrindiniai įvykiai |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
|
Gylusis mokymasis |
|
|
Veido aptikimas |
Yes |
|
Perimetro apsauga |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
|
Bendriniai |
|
|
Apjungimo būdai |
Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audible warning
*Note: External device is required. |
|
Kalbos |
33 languages:
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
|
Pagrindinės funkcijos |
Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel
counter |
|
Programos perkrovimas |
Yes |
|
Laikymo sąlygos |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Darbinės sąlygos
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Maitinimas |
12 VDC, 0.65 A, max. 7.8 W
PoE: (802.3af, 36 V to 57 V), 0.25A to 0.15 A, max. 8.8 W |
|
Energijos sąnaudos |
Ø5.5 mm coaxial power plug |
|
Maitinimo jungtis |
12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3 |
|
Medžiaga |
Metal except for trim ring |
|
Matmenys |
Ø138.3 × 124.5 mm (Ø5.4″ × 4.9″) |
|
Pakuotės matmenys |
170 × 170 × 150 mm (6.9" × 6.9" × 5.9") |
|
Svoris |
Approx. 800 g (1.8 lb.) |
|
Svoris su pakuote |
Approx. 1093 g (2.4 lb.) |
|
Patvirtinimai |
|
|
EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN
61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
(ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
|
Saugumas |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 );
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
|
Aplinka |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
|
Apsauga |
Ingression protection: IP67 (IEC 60529-2013) |
