Sensorius | 1/3" progressive scan CMOS |
Min. apšvietimas | Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON) |
Užrakto greitis | 1/3s to 1/100,000 s, support slow shutter |
Objektyvas | 2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117° |
Objektyvo montavimas | M12 |
Diena / naktis | IR cut filter |
Skaitmeninis triukšmo slopinimas | 3D DNR |
Reguliavimas | Pan: 0° to 355°, tilt: 0°to 70° |
WDR | Digital WDR |
Vaizdo suspaudimas | Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG |
H.264 tipas | Baseline Profile/Main Profile/High Profile |
H.264+ | Main stream supports |
H.265 tipas | Main Profile |
H.265+ | Main stream supports |
Vaizdo sparta | 32 Kbps to 8 Mbps |
Maks. raiška | 2560 × 1440 |
Kadrai per sek. | 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Vaizdo nustatymai | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Dienos/nakties perjungimas | Auto, scheduled |
Tinklinis talpinimas | NAS (NFS, SMB/CIFS) |
Pavojaus signalo sukėlimas | Motion detection, video tampering alarm, illegal login |
Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
Pagrindinės funkcijos | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
Reset mygtukas | Yes |
Veikimo sąlygos | -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing) |
Maitinimas | 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
Energijos suvartojimas | 12 VDC, 0.4 A, Max: 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W |
IP apsaugos klasė | IP67 |
IR apšvietimas | Up to 30 m |
Smūgio apsauga | IK10 |
Išmatavimai | Camera: Ø 111 mm × 82.4 mm ( 4.4" × 3.2") With package: 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3") |
Svoris | Camera: approx. 410 g (0.9 lb.) With package: approx. 610 g (1.3 lb.) |
