Sensorius | 1/2.8" progressive scan CMOS |
Min. apšvietimas | Color: 0.01Lux @(F1.2,AGC ON),0 Lux with IR |
Užrakto greitis | 1/3s to 1/100,000 s, supportslow shutter |
Objektyvas | 2.8 mm @F2.0, horizontal field of view 105°, 4 mm @F2.2, horizontal field of view 84° 6 mm @F2.0, horizontal field of view 55° |
Objektyvo montavimas | M12 |
Diena / naktis | IR cut filter with auto switch |
Reguliavimas | Pan: 0° to 355°, tilt: 0°to 70° |
Skaitmeninis triukšmo slopinimas | 3D DNR |
Platus dinaminis diapazonas | Digital WDR |
Vaizdo suspaudimas | Main stream: H.264+/H.264 Sub stream: H.264/MJPEG |
H.264 Tipas | Baseline profile/Main profile |
Vaizdo sparta | 32 Kbps to8 Mbps |
Maks. raiška | 1920 × 1080 |
Pagr. srautas | 50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720) |
Antrinis srautas | 50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288,320 × 240) 60Hz: 30fps @(704 ×480, 640 × 480, 352 × 240,320 × 240) |
Vaizdo nustatymai | Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
Dienos / naktie perjungimas | Support auto, scheduled |
Kitos funkcijos | Mirror, BLC (area configurable), region of interest (support 1 fixed region) |
Tinklinis talpinimas | NAS (NFS,SMB/CIFS) |
Aptikimai | Motion detection |
Pavojaus signalai | Video tampering, network disconnected, IP address conflicted |
Protokolai | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, NTP,UPnP,SMTP,IGMP,802.1X,QoS,IPv6, Bonjour |
Standartai | ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI |
Pagrindinės funkcijos | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
Reset mygtukas | Support |
Darbo sąlygos | -30 °C to60 °C (-22 °F to140 °F), humidity: 95% or less (non-condensing) |
Maitinimas | 12V DC± 25%, PoE (802.3af) |
Energijos suvartojimas | Max. 5 W |
Apsaugos lygis | IP67, IK10 |
IR apšvietimas | Up to 30 m |
Išmatavimai | Φ111 mm × 82 mm (4.4" × 3.2") |
Svoris | 500 g (1.1 lb.) |
