| Kamera | |
| Sensorius | 1/1.8" Progressive Scan CMOS |
| Min. apšvietimas | Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Lėtas užraktas | Yes |
| Diena & naktis | IR Cut Filter |
| WDR | 120 dB |
| Kampo pasirinkimas | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lęšiai | |
| Lęšių tipai | Fixed lens, 2.8/4/6 mm |
| Diafragma | F1.6 |
| FOV | 2.8 mm, horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 120°
4 mm, horizontal FOV: 87.1°, vertical FOV: 47.4°, diagonal FOV: 101.8°
6 mm, horizontal FOV: 50.8°, vertical FOV: 27.6°, diagonal FOV: 60° |
| Lęšių montavimas | M16 |
| Apšvietimas | |
| IR nuotolis | -2I: up to 60 m
-4I: up to 80 m |
| Bangų ilgis | 850 nm |
| Vaizdo įrašai | |
| Maks. raiška | 3840 × 2160 |
| Pagrindinis srautas | 50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720)
60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720) |
| Pagalbinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas | 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Vaizdo suspaudimas | Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264 |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| H.265 tipas | Main Profile |
| Vaizdo bitų greitis | 32 Kbps to 16 Mbps |
| SVC | H.264 and H.265 encoding support |
| Išmanios funkcijos | |
| Perimetro apsauga | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human&Vehicle classification) |
| Veido atpažinimas | Yes |
| Paprasti įvykiai | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Sujungimo metodas | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture |
| ROI | 1 fixed region for main stream, sub-stream and third stream |
| Nuotrauka | |
| Vaizdo gerinimas | BLC, HLC, 3D DNR |
| Vaizdo nustatymai | Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Dienos/nakties jungiklis | Day/Night/Auto/Schedule |
| Tinklas | |
| Tinklo saugykla | microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Apsauga | Password protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Tiesioginis vaizdo žiūrėjimas | Up to 6 channels |
| Naudotojas/transliuotojas | Up to 32 users, 3 levels: administrator, operator and user |
| Klientas | iVMS-4200, Hik-Connect, Hik-Central |
| Interneto naršyklės | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Sąsaja | |
| Bendravimo sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Vidinė atmintis | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Pagrindinis | |
| Iternetinio meniu kalbos | 32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Pagrindinės funkcijos | Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter |
| Restartavimas | Reset via reset button on camera body, web browser and client software |
Paleidimo ir veikimo
sąlygos | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Laikymo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Energijos šaltinis | 12 VDC ± 25%, Φ 5.5 mm coaxial power plug; reverse polarity protection; PoE (802.3af, class 3) |
| Energijos suvartojimas ir galia | -2I: 12 VDC, 0.63 A, max. 7.5 W; PoE (802.3af, 36 V to 57 V), 0.25 A to 0.16 A, max. 9 W
-4I: 12 VDC, 0.88 A, max. 10.5 W; PoE (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12 W |
| Medžiaga | Metal |
| Matmenys | Camera: Φ 105 × 290 mm (Φ 4.1" × 11.4")
With package: 386 × 156 × 155 mm (15.2" × 6.1" × 6.1") |
| Svoris | Camera: approx. 1270 g (2.8 lb.)
With package: approx. 1510 g (3.3 lb.) |
| Patvirtinimai | |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950- 1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Chemija | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Apsauga | Ingress protection: IP67 (IEC 60529-2013) |
