Sensorius | 1/2.5" Progressive Scan CMOS |
Signalo sistema | PAL/NTSC |
Min. apšvietimas | Color: 0.008 lux @(F1.2, AGC ON), 0.014 lux @(F1.6, AGC ON), 0 lux with IR |
Užrakto laikas | 1/3 s to 1/100,000 s |
Lėtas užraktas | Support |
Objektyvas | 12 mm, horizontal FOV: 25°, vertical FOV: 14°, diagonal FOV: 29° |
Objektyvo montavimas | M12 |
Reguliavimas | Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360° |
Diena/naktis | IR cut filter with auto switch |
Platus dinaminis diapazonas | 120 dB |
Skaitmeninis triukšmo slopinimas | 3D DNR |
Vaizdo sparta | 32Kbps~16Mbps |
Vaizdo suspaudimas | H.265+/H.265/H.264+/H.264/MJPEG |
Trigubas srautas | Yes |
Maks. vaizdo raiška | 2688 × 1520 |
Kadrai per sek. | 50Hz: 25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080) 60Hz: 30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080) |
Antrinis srautas | 50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
Trečias srautas | 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
Vaizdo ryškinimas | BLC/3D DNR/HLC |
Vaizdo nustatymai | Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client software or web browser |
Dienos/nakties perjungimas | Day/Night/Auto/Schedule |
Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Pagrindinės funkcijos | One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Sistemos suderinamumas | ONVIF (PROFILE S, PROFILE G), ISAPI |
Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
Vidinė atmintis | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Elgesio analizavimas | Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
Veikimo sąlygos | -30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity 95% or less (non-condensing) |
Maitinimas | 12 VDC ± 25%, Φ 5.5 mm coaxial plug power PoE(802.3af, class 3) |
Energijos suvartojimas | 12 VDC, 1 A, max: 11.5 W PoE (802.3af, 36V to 57V), 0.4 A to 0.2 A, max. 12.9 W |
IP apsaugos klasė | IP67 |
IR apšvietimas | Up to 80m |
Išmatavimai | Camera: Φ104.8 × 299.7 mm (Φ4.13″ × 11.8″)
Package: 386 × 156 × 155 mm (15.2″ × 6.14″ × 6.1″) |
Svoris | Camera: 1200 g (2.65 lb.) |
