| Pavadinimas | Aprašymas |
| Sensorius | 1/2.8" Progressive Scan CMOS |
| Min. apšvietimas | 0.0035 @ F1.0 (1/30 s, AGC ON), 0 Lux with LED on |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Išlaikymas | Yes |
| WDR | 120dB |
| Kampo valdymas | Pan: 0 to 360°, tilt: 0 to 90°, rotation: 0 to 360° |
| DNR | 3D DNR |
| Objektyvas | 2.8/4/6 mm |
| Auto-Iris | No |
| Diafragma | F1.0 |
| Fokusavimas | Fixed |
| FOV | 2.8 mm, horizontal FOV: 112°, vertical FOV: 57°, diagonal FOV: 138° 4 mm, horizontal FOV: 89°, vertical FOV: 47°, diagonal FOV: 106° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 63° |
| Montavimas | M16 |
| Baltos spalvos diapazonas | 30m |
| Maks. raiška | 1920 × 1080 |
| Pagrindinis srautas | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Vaizdo suspaudimas | Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| H.265 tipas | Main Profile |
| Vaizdo bitų greitis | 32 Kbps to 8 Mbps |
| SVC | Yes |
| Elgesio analizė | Line crossing detection, intrusion detection |
| ROI | Support 1 fixed region for main stream |
| Vaizdo pagerinimas | BLC/3D DNR/HLC |
| Vaizdo nustatymas | Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Tinklo saugykla | Support micro SD/SDHC/SDXC card (128 G) local storage, NAS (NFS,SMB/CIFS), ANR |
| Protocolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Transliavimas | Up to 6 channels |
| User/Host | Up to 32 users,3 levels: Administrator, Operator and User |
| Klientas | iVMS-4200, Hik-Connect, Hik-Central |
| Naršyklė | IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11 |
| Pavojaus signalas | Motion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Ryšio sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Vidinė saugykla | Built-in micro SD/SDHC/SDXC slot, up to 128 GB |
| Programinės įrangos versija | V5.5.53 |
| Pagrindinės funkcijos | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy masks, IP address conflict, flash log |
| Perkrovimas | Yes |
| Startavimo ir veikimo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F) |
| Maitinimas | 12 VDC ± 20%, PoE: 802.3af |
| Suvartojimo įtampa ir srovė | 12VDC, 0.4 A, max. 5 W; PoE:(802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 6.5 W |
| Medžiaga | Camera body: Front cover: plastic, back cover: metal,Bottom base: plastic |
| Matmenys | 85 × 85 × 218 mm (3.3" × 3.3" × 8.6") |
| Svoris | 0.680 kg (1.5 lb.) |
| Apsauga | IP67 |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
