Sensorius: | 1/2.7" Progressive Scan CMOS |
Signalas: | PAL/NTSC |
Min. apšvietimas: | 0.005 Lux @ (F1.2, AGC ON) |
Užrakto laikas: | 1/3 s ~ 1/100,000s |
Užlaikymas: | Support |
Montavimas: | CS mount |
Auto lęšis: | DC drive |
Diena/Naktis: | IR cut filter |
WDR: | 120 dB |
DNR: | 3D DNR |
Vaizdo suspaudimas: | Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG |
H.264 tipas: | Baseline Profile / Main Profile / High Profile |
H.264+ | Main stream supports |
H.265 tipas: | Main profile |
H.265+ | Main stream supports |
Sparta: | 32Kbps~ 8Mbps |
Garso suspaudimas: | G.711/G.722.1/G.726/MP2L2/PCM |
Garso suspaudimo sparta: | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2) |
Raiška: | 1920 x 1080 |
Pagrindinis srautas | 50Hz: 25fps(1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Antras srautas | 50Hz: 25fps (640 x 480, 640 x 360, 320 x 240)
60Hz: 30fps (640 x 480, 640 x 360, 320 x 240) |
Tretinis srautas | Independent with Main Stream and Sub Stream, up to
50Hz: 25fps(1920 × 1080); 60Hz: 30fps (1920 × 1080) |
Vaizdo apdorojimas | BLC/3D DNR |
Vaizdo nustatymai: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness, AGC, White Balance adjustable by client software or web browser |
Diena/naktis perjungimas: | Auto/Schedule/Triggered by Alarm In |
Tinklo saugykla: | Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR |
Pavojaus trigeris: | Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
Protokolai: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, ;RTSP, RTCP, PPPoE, NTP, UPnP, ;SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Garsas: | 1-ch 3.5 mm audio in( Mic in/Line in)/out interface, 1 build-in Microphone |
Garso įvestis/išvestis | Yes, mono |
Garso dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
Komunikaciniė sąsaja | 1 RJ45 10M/100M self-adaptive Ethernet port, 1 RS232, 1 RS485 |
Pavojaus signalas | DS-2CD2821G0: 1 input, 1 output (max. DC 12 V, 30 mA) DS-2CD2821G0 (AC24V/DC12V): 1 input, 1 output (max. DC 24 V, 1 A or max. AC 110 V, 500 mA) |
Vaizdo išvestis | 1Vp-p Composite Output (75 Ω, BNC) |
Vidinė saugykla: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Aplinkos triukšmų slopinimas | Support |
Vaizdo analizė | Line crossing detection, intrusion detection |
Darbo sąlygos | -10 °C ~ 50 °C (-14 °F ~ 122 °F)
Humidity 95% or less (non-condensing) |
Maitinimas | DC: 12 V ± 25% AC: 24 V ± 25% (AC24V models support) PoE: 802.3af, class 3 Terminal block |
Energijos suvartojimas | DC: 12 V, 0.4 A, max: 4.8 W AC: 24 V, 0.2 A, max: 4.8 W (AC24V model supports) PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max: 6 W |
Medžiagos | Shell: plastic, camera body: metal |
Išmatavimai: | Camera: 68 × 56 × 143 mm (2.7" × 2.2"× 5.6") With package: 172 × 110 × 99 mm (6.8" × 4.3"× 3.9") |
Svoris: | Camera: 440 g (1 lb.) With package: 600 g (1.3 lb.) |
