16 prievadų switch ZyXEL GS1100-16

Application

Home and small office

Chassis type

Desktop

Description

The ZyXEL GS1100 Series is the best solution for instant Gigabit connectivity in office environments demanding silent operation and better energy efficiency. With power-saving functions, Gigabit Ethernet and a fanless design, the GS1100 Series provides plug-and-play simplicity for high-bandwidth network applications.The ZyXEL GS1100 Series consists of four unmanaged switches: the GS1100-8HP, GS1100-16, GS1100-24 and GS1100-24E. The GS1100-16 and GS1100-24E feature 16 and 24 GbE ports. The GS1100-24 is a 24-port Gigabit switch with 2 additional open Gigabit SFP slots, while the GS1100-8HP is an 8-port Gigabit switch that complies with the IEEE 802.3at Power over Ethernet (PoE) Plus standard, providing 4 PoE ports with up to 30 watts per port.- Traffic detection — Energy Efficient Ethernet (EEE) complianceThe IEEE 802.3az Energy Efficient Ethernet (EEE) feature automatically detects network traffic and adjusts power consumption dynamically, enabling the switch to reduce power consumption during low link utilization periods. The GS1100 Series comes with IEEE 802.3az on/off button to help reduce power consumption. This button allows users to keep the best performance without transmit impacted or to have green support of Energy Efficient Ethernet mode with a simple push of a button.- Inactive link detectionThe inactive link detection function automatically reduces power usage when inactive links or devices are detected. The ZyXEL GS1100 Series can adjust power consumption according to link status and the number of active network devices.- Cable length detectionThis green feature enables the switch to automatically detect the length of connected Ethernet cables and adjust power usage accordingly. The shorter the cable length, the less power it consumes.

Dimensions

Height: 42 mmWidth: 215 mmDepth: 133 mm

Fan

No

MAC address table size

8000

Memory buffer

256KB

Network architecture

GigabitEthernet

Number of 10/100 Mbps ports

None

Number of 10/100/1000 Mbps ports

16

Number of COMBO ports

None

Number of PoE ports (PoE & PoE+)

None

Number of SFP ports

None

Other features

- Non-blocking, wire-speed transmission- Auto MDI/MDI-X support- IEEE 802.3az compliant- Fanless design for silent operation- IEEE 802.3x flow control supported- IEEE 802.1p CoS supported- Jumbo frame support up to 10 K bytes (GS1100-24/24E)- IEEE 802.3at PoE Plus standard with 30 W per port (GS1100-8HP)

Power consumption

6.4W

Power supply

External

Support for Jumbo frames

Yes

Supported protocols and standards

IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-Tx EthernetIEEE 802.3ab 1000Base-T EthernetIEEE 802.3az: EEE IEEE 802.3x: IEEE 802.1p flow control supported, class of service

Switch class

Unmanaged

Throughput

32GB/s

Weight

1kg
